產品簡介
DIODES 的 SBR30A60CTB 這種超級勢壘整流器（SBR?）二極管設計用于滿足汽車應用的嚴格要求。它非常適合用作：
極性保護二極管
再循環二極管
開關二極管
產品規格
品牌 DIODES
型號 SBR30A60CTB
名稱 30A超勢壘整流器
產地 臺灣
封裝 SOD123F
產品參數
AEC Qualified Yes
Compliance (Only Automotive supports PPAP) Standard
Configuration Dual
Maximum Average Rectified Current IO (A) 30
Peak Repetitive Reverse Voltage VRRM (V) 60
Peak Forward Surge Current IFSM (A) 180
Forward Voltage Drop VF (V) 0.63
@ IF (A) 30
Maximum Reverse Current IR (μA) 500
@ VR (V) 60
主要特征
專利SBR技術提供卓越的雪崩性能比肖特基二極管更強大的性能，確保更堅固耐用可靠的最終應用。
降低了超低正向電壓降（VF）；效率更高以及冷卻器操作。
減少高溫反向泄漏；提高了可靠性防止高溫運行中的熱失控故障
